CWT-C OS Update for CPU board 0501-E0150
| Important: The scripts copyCleanNK.bat and copyNK.bat assumes that the SD card is located at drive E:\. If another drive is desired change the drive letter in SetSDCardDrive.bat Warning: This action will format the SD card and all files on it will be deleted. |
This card will start up the system and flash both NK.bin and EBOOT.bin to respective flash.
1.Extract the SdBootCardSoftware.zip to a folder on your desktop. You will find the following files:
File |
Used for |
Cfimager126.exe |
|
copyCleanNK.bat |
Formats the SC card and copies the installation OS NK.nb0 to the SD Card |
copyNK.bat |
copies the installation OS NK.nb0 to the SD card on an already formatted installation SC card |
NK.nb0 |
Contains the OS needed to install the final OS into the terminal. DO NOT replace this file with any NK.nb0 from the OS image folder containing the final terminal OS |
ProdFlasher.exe |
The boot loader to start the installation program. This file must be renamed to cwtapploader.exe as the terminal always searches for a file with that name to load a CWT application |
SetSDCardDrive |
A batch file to set the correct drive letter |
2.Copy the SD Card image NK.nb0 into the same folder if not delivered in zip-file. This file will install the final OS and display the progress when booting the terminal.
3.Put the card into your PC’s SD card reader
4.Run copyCleanNK.bat to format the SD card and to install the NK.bn0 into the unallocated (=hidden) partition on the SD card
5.Copy ProdFlasher.exe to SD card root
6.Rename ProdFlasher.exe to cwtapploader.exe
7.Create a IMG folder in the SD card root
8.Copy the OS files NK.bin and EBOOT.bin for the OS version to install in the terminal to <SD card root>\IMG folder
